Improved Noise Immunity
The PowerBeam ac focuses RF energy into a narrow beamwidth, blocking or filtering out unwanted noise for superior signal clarity. This is especially beneficial in environments crowded with similar-frequency RF signals.
Integrated Design
Ubiquiti’s InnerFeed technology integrates the radio into the antenna feedhorn, eliminating cable losses for improved performance. With high performance and an innovative mechanical design, the PowerBeam ac is both versatile and cost-effective to deploy.
Specifications
- Dimensions: 620 × 620 × 386 mm (24.41 × 24.41 × 15.2″)
- Weight: 6.4 kg (14.11 lbs)
- Power Supply: 24 V, 0.5 A Gigabit PoE
- Max. Power Consumption: 8.5 W
- Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Supported Voltage Range: 20–26 VDC
- Gain: 29 dBi
- Networking Interface: (1) 10/100/1000 Mbps Ethernet Port
- Processor: Atheros MIPS 74Kc, 720 MHz
- Memory: 128 MB DDR2, 16 MB Flash
- LEDs: (1) Power, (1) LAN, (4) WLAN
- Signal Strength LEDs: Software-adjustable for custom RSSI levels
- Max. VSWR: 1.6:1
- Polarization: Dual Linear
- Enclosure: Outdoor UV-stabilized plastic
- Mounting: Pole-mount (kit included)
- Wind Survivability: 200 km/h (125 mph)
- ESD/EMP Protection: Air ≥ 24 kV, Contact ≥ 24 kV
- Operating Temperature: −40 to 70 °C (−40 to 158 °F)
- Operating Humidity: 5 to 95% noncondensing
- Wireless Approvals: FCC, IC, CE
- Compliance: RoHS
- Environmental Tests:
- Salt Fog: IEC 68-2-11 (ASTM B117), MIL-STD-810 G Method 509.5
- Vibration: IEC 68-2-6
- Temperature Shock: IEC 68-2-14
- UV: IEC 68-2-5 at 40 °C, ETS 300 019-1-4
- Wind-Driven Rain: ETS 300 019-1-4, MIL-STD-810 G Method 506.5
