Improved Noise Immunity
The LiteBeam 5AC Gen 2 focuses RF energy into a tighter beamwidth, reducing interference by blocking or filtering out unwanted signals. This ensures better noise immunity, especially in environments crowded with RF signals of similar frequencies.
Innovative Design
With Ubiquiti’s InnerFeed® technology, the radio is integrated directly into the feedhorn, eliminating the need for cables and minimizing signal loss. Its high-performance design, combined with mechanical versatility, makes it a cost-effective and easy-to-deploy solution.
Specifications
- Dimensions: 358 × 271.95 × 272.5 mm (14.09 × 10.71 × 10.73″)
- Weight: 800 g (1.76 lb) without mount; 980 g (2.16 lb) with mount
- Power Supply: 24V, 0.3A Gigabit PoE adapter (included)
- Max Power Consumption: 7W
- Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
- Voltage Range: 24V ±10%
- Gain: 23 dBi
- Networking Interface: 1× 10/100/1000 Ethernet port
- Processor: MIPS 74Kc
- Memory: 64 MB DDR2
- LEDs: Power, Ethernet
- Channel Sizes: PtP: 10/20/30/40/50/60/80 MHz | PtMP: 10/20/30/40 MHz
- Enclosure: Reflector (SGCC 0.6T) / Plastic: PC
- Mounting: Pole-mount kit (included)
- Wind Loading: 275 N @ 200 km/h (61.8 lbf @ 125 mph)
- Wind Survivability: 200 km/h (125 mph)
- ESD/EMP Protection: ±24 kV Contact / Air
- Operating Temperature: −40 to 70°C (−40 to 158°F)
- Operating Humidity: 5–95% noncondensing
- Certifications: CE, FCC, IC
