Specifications
Hardware & Form Factor
- Weight: 58 lb (26.3 kg)
- Dimensions: 17 × 18 × 7 in (43 × 43.5 × 17.8 cm)
- Form Factor: 4U rack-mountable
- Power Supply: Dual, redundant, hot-swappable 850 W
- Fans: Dual, redundant, hot-swappable
- Input Power: 100–240 VAC, 50/60 Hz
- Maximum Power Consumption: 750 W
- Front LED Display
System & Performance
- Operating System: SonicOS
- Cores: 96
- Memory: 64 GB RAM
- Storage: 80 GB SSD/Flash
- 10 GbE Interfaces: 6 × 10-GbE SFP+
- Management Interfaces: 1 GbE, 1 Console
Throughput & Connections
- Firewall Inspection: 40 Gbps
- Application Inspection: 30 Gbps
- IPS: 30 Gbps
- Anti-Malware Inspection: 12 Gbps
- VPN Throughput: 20 Gbps
- Connections per Second: 640,000/sec
- Max SPI Connections: 12M
- Max DPI Connections: 10M
VPN Capabilities
- Site-to-Site Tunnels: Unlimited
- IPSec VPN Clients: 2,000 (16,000*)
- SSL VPN Licenses: 50 (80,000*)
- Encryption: DES, 3DES, AES (128/192/256-bit)
- Authentication: MD5, SHA-1
- Key Exchange: Diffie-Hellman Groups 1, 2, 5, 14
- Route-Based VPN Support: RIP, OSPF
Networking & Protocols
- IP Assignment: Static, DHCP, PPPoE, L2TP, PPTP client; DHCP server/relay
- NAT Modes: 1:1, many:1, 1:many, flexible NAT, PAT, transparent mode
- VLAN Interfaces: 512
- Routing Protocols: BGP*, OSPF, RIPv1/v2, static, policy-based, multicast
- QoS: Bandwidth priority, max/guaranteed bandwidth, DSCP marking, 802.1p
- Authentication: XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal database, Terminal Services, Citrix
- IPv6 Support: Dual-stack, RFDPI, firewall, VPN, NAT, ICMPv6, DHCPv6, DNSv6
- VoIP Support: Full H.323 v1–5, SIP
- Standards: TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications & Compliance
- Certified: FCC Class A, CE, C-Tick, VCCI, MIC, UL, cUL, TUV/GS, CB, NOM, RoHS, WEEE
- Pending: FIPS 140-2, Common Criteria EAL4+, NEBS, ICSA Firewall
Environmental
- Operating Temperature: 5–40°C (40–105°F)
- Humidity: 10–90%, non-condensing
