Benefits
- Advanced intrusion prevention with anti-evasion technology blocks the latest attacks.
- Network-based anti-malware with CloudAssist offers 24/7 protection from malicious threats.
- SSL decryption and inspection secure traffic hidden in encrypted data.
- Integrated wireless controller enables easy deployment of Clean Wireless technology.
- Supports seamless user authentication across SSO, LDAP, and RADIUS.
- WAN failover and load balancing ensure business continuity and optimized network performance.
- Content and URL filtering control access while maintaining productivity.
- Real-time application visibility, control, and bandwidth management provide network insights.
- High port density supports complex network environments.
- Integrated 10 Gb SFP+ interfaces future-proof bandwidth expansion.
General Specifications
- Device Type: Security appliance
- Form Factor: 1U rack-mountable
- Dimensions: 17″ W × 19.1″ D × 1.8″ H
- Weight: 18.08 lbs
- Built-in Devices: Status LCD
Processor / Memory / Storage
- RAM: 16 GB
Networking
- Connectivity: Wired, Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
- Network Protocols: TCP/IP, PPTP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
- Routing Protocols: OSPF, RIP-1, RIP-2, static IP, policy-based routing (PBR)
- Remote Management: SNMP, HTTP, HTTPS, SSH, CLI
Performance
- Firewall throughput: 20 Gbps
- Application throughput: 8 Gbps
- IPS throughput: 8 Gbps
- Anti-malware throughput: 4.5 Gbps
- VPN throughput: 10 Gbps
- Forwarding (IMIX): 5.5 Gbps
Capacity
- Max application cores: 32
- VPN tunnels (site-to-site): 10,000
- VPN client licenses: 2,000
- SSL VPN tunnels: 2
- Virtual interfaces (VLANs): 512
- Max connections/users: 1,250,000
- DPI connections: 1,000,000
Features
- NAT, VPN, load balancing, LDAP, SPI, DoS prevention, HA, IPS, URL filtering, DPI, DDoS prevention, anti-malware, QoS, RADIUS, DHCP, bandwidth control, hot-swappable dual fans, LACP, NetFlow, IPFIX
- Encryption & Authentication
- Algorithms: DES, 3DES, MD5, SHA-1, AES (128/192/256), FIPS 140-2
- Authentication: RADIUS, LDAP, Active Directory, XAUTH
Compliance & Standards
- IEEE 802.1p, FCC Class A, UL, TUV GS, VCCI, C-Tick, BSMI, cUL, NOM, CB, RoHS, KCC, WEEE, ANATEL
- IP Telephony
- VoIP protocols: H.323, SIP
- Expansion & Connectivity
- Expansion Slots: 1 total (1 free)
- Interfaces: 1 x 1000Base-T (management), 2 x USB-A, 1 x management RJ-45, 8 x 1000Base-T, 8 x 1000Base-X SFP, 4 x 10GBase-X SFP+
- Rack Mount Kit: Included
Power
- Internal hot-plug power supply, 2 installed (max 2)
- Voltage: AC 120/230 V, 50–60 Hz
- Operational power: 300 W
- Power provided: 850 W
Software
- OS: SonicOS
Environmental Parameters
- Operating Temperature: 32–104 °F
- Humidity: 10–90% non-condensing
