FEATURES
GIGABIT PERFORMANCE
Stream high-bandwidth files and minimize transfer times to connected devices with reliable Gigabit speeds.
PLUG-AND-PLAY INSTALLATION
Quickly extend your office network with an easy, hassle-free setup.
QUALITY OF SERVICE (QoS)
Prioritize traffic for critical devices or applications, ensuring smooth data flow even during network congestion.
AUTO-SENSING PORTS
Automatically adjusts speed for each connected device for optimal performance.
TECHNICAL SPECS
- Network Standards: IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3az, 802.3af, 802.3at (PoE+)
- Ports: 8-port switch with 4 PoE+ ports (1–4), 50 W PoE power budget
- LEDs: Link, speed, activity, PoE indicators
- Performance: 64B frame forwarding rate: 1.488 Mpps (1000M), 0.1488 Mpps (100M), 0.01488 Mpps (10M)
- MAC Address Table Size: 8,000 entries
- Bandwidth: 16 Gbps non-blocking
- Fans: None
- Power: 54 VDC, 1.2 A, external supply; max 7 W
- Power-Saving: Cable detection, sleep mode
- Dimensions: 210 x 104 x 25 mm | Weight: 0.50 kg
- Operating Temp: 0–50°C | Storage Temp: -40–70°C
- Operating Humidity: 10–90% | Storage Humidity: 10–90%
- Mounting: Wall
- QoS: 802.1p and DSCP
- Compliance: FCC Class A, CE
- Warranty: 5 Years
