Features
- High-Speed Gigabit Performance: Delivers fast, reliable transfer of high-bandwidth files across connected devices, minimizing delays and interference.
- Plug-and-Play Convenience: Simple installation lets you instantly expand your office network without complex configuration.
- Auto-Sensing Ports: Automatically optimize speed for each connected device.
- Energy-Efficient Design: Smart power and auto power-down features reduce energy usage on unused ports or short cable runs.
Technical Specs
- Ports: 5 Gigabit Ethernet (10/100/1000)
- Standards: IEEE 802.3, 802.3u, 802.3x, 802.3ab, 802.3az
- Performance: Full line rate; 64B frame forwarding: 1.488Mpps (1000M), 0.1488Mpps (100M), 0.01488Mpps (10M)
- MAC Address Table: 2,000 entries
- Bandwidth: 10 Gbps (non-blocking)
- LED Indicators: Link/activity
- Fans: None
- Power: 110–240V AC, 50/60Hz; 5V DC, 1.0A; external supply
- Power Consumption: 0.42–2.22W with energy-saving modes
- Dimensions: 120 × 88 × 26 mm; Weight: 0.252 kg
- Operating Temp: 0–50°C; Storage Temp: -40–70°C
- Humidity: 10–90% RH (non-condensing)
- Mounting: Wall-mountable
- Compliance: FCC Class B, CE
- Warranty: 5 years
