Quality of Service (QoS) Traffic Prioritization
The LGS326 switch offers extensive QoS features to prioritize network traffic, ensuring optimal performance for real-time voice, video applications, and high-bandwidth data transfers such as large file uploads or video streaming.
Network Expansion
Easily expand your network with Spanning Tree Protocol (STP) and Storm Control, which help manage both planned and accidental cable loops, ensuring reliable and scalable connectivity.
Advanced Network Security
Protect your network with port authentication and MAC-based port security. Enhanced DHCP snooping and IP-MAC binding maintain data integrity and prevent unauthorized access or attacks.
Technical Specifications
- Network Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3ad, 802.3az, 802.1d, 802.1Q/p, 802.1X
- Memory: 128 MB
- LED Indicators: System (blue), Link/Act (green)
- System Power Consumption (without PoE): 110V: 17.62W, 220V: 17.72W
- Forwarding Rate: 38.69 Mpps
- Switching Capacity: 52 Gbps
- Jumbo Frame Support: 9K
- Dimensions (LxWxH): 440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.)
- Weight: 2.424 kg (5.33 lbs)
- Power Input: 100–240V, 50–60 Hz
- Operating Temperature: 0 to 50°C (32 to 122°F)
- Storage Temperature: -40 to 70°C (-40 to 158°F)
- Operating Humidity: 10–90% RH
- Storage Humidity: 10–90% RH (non-condensing)
Spanning Tree & Link Aggregation
Supports IEEE 802.1d STP, 802.1w Rapid STP, and 802.3ad LACP for up to 4 groups with 8 ports per group, enabling loop-free topology and aggregated bandwidth.
VLAN & IGMP Snooping
Supports port-based and 802.1q VLANs, Management VLAN, Guest VLAN, and dynamic VLAN assignment via RADIUS with 802.1x authentication. IGMP v1/v2/v3 snooping ensures efficient multicast traffic management for up to 256 groups.
Additional Features
- Head-of-line (HOL) blocking prevention
- Port mirroring for traffic analysis
- Storm control for broadcast, flooding, and multicast traffic
- Embedded RMON for remote monitoring and management
- Security features including 802.1x authentication, DHCP snooping, IP-MAC binding, and access control
- QoS class of service: port-based, 802.1p, IPv4/v6 DSCP-based with 4 hardware queues and WRR scheduling
- Combo RJ45 + SFP ports: 2 (ports g25, g26)
- Copper FE/GE Ports (RJ45): 24 (g01–g24)
- Green Power Mode: EEE+, Short Reach + Energy Detect
- Total System Ports: 26GE
- MAC Address Table Size: 8K
