Key Features
- Quality of Service (QoS) Traffic Prioritization: Advanced QoS ensures real-time voice, video, and high-bandwidth applications run smoothly by prioritizing network traffic. Ideal for streaming, video conferencing, and large file transfers.
- Integrated Power over Ethernet Plus (PoE+): Simplifies installation by delivering power through network cables, eliminating the need for separate power outlets. Fully backward compatible with 802.3af PoE standard, supporting a total of 16 PoE+ ports with 125W dedicated power.
- Network Expansion: Easily build a scalable network with Spanning Tree Protocol (STP) and Storm Control to prevent network loops and congestion, supporting safe multi-switch deployments.
- Advanced Security: Protects network integrity with port authentication, MAC-based security, DHCP snooping, and IP-MAC binding. Prevents unauthorized access and maintains secure traffic flow.
Technical Specifications
- Ports: 16 PoE+ + 2 combo (RJ45 + SFP) ports, total 18 Gigabit Ethernet ports
- Switching Capacity: 36 Gbps, Forwarding Rate: 26.79 Mpps
- Memory: 128 MB
- MAC Address Table: 8K entries
- Jumbo Frame: 9K
- Fans: 1 x 8,200 rpm
- Power Input: 100–240V, 50–60 Hz, 2.5A max
- PoE+ Power Budget: 125W
- Dimensions: 440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in.)
- Weight: 2.784 kg (6.12 lbs)
Network & Management Features
- VLANs: Port-based, 802.1q tag-based, Management VLAN, Guest VLAN; supports 128 active VLANs
- Link Aggregation: IEEE 802.3ad LACP, up to 4 groups
- Auto Voice VLAN: Automatic assignment for voice traffic with appropriate QoS levels
- IGMP Snooping: Efficient multicast handling with support for 256 groups
- Port Mirroring: Mirror traffic from up to 4 ports for network analysis
- QoS Scheduling: Priority queuing and weighted round-robin (WRR) with 4 hardware queues
- Green Power: EEE+, Short Reach + Energy Detect
Security & Monitoring
- 802.1x Radius authentication, DHCP snooping, IP-MAC binding, port security, storm control
- Remote monitoring via RMON agent
- Management interfaces: HTTP, HTTPS, Telnet, SNMP (v1, v2c), firmware upgrades via HTTP/HTTPS or TFTP
