Features & Specifications
Quality of Service (QoS) Traffic Management
The LGS318 switch offers advanced QoS features to prioritize network traffic, ensuring smooth performance for real-time voice and video applications, high-bandwidth uploads/downloads, and intensive graphics transfers.
Network Expansion & Reliability
Easily expand your network using Spanning Tree Protocol (STP), Rapid STP, and Multiple STP support to prevent accidental loops. Storm Control monitors and suppresses excessive traffic to maintain network stability. Link aggregation (IEEE 802.3ad) allows up to 4 groups of 8 ports for increased bandwidth.
Advanced Security
Port-based authentication and MAC-based port security protect network access, while DHCP snooping and IP-MAC binding ensure data integrity and prevent unauthorized access. RMON support enables enhanced traffic monitoring and analysis.
VLAN & Multicast Support
Supports up to 256 multicast groups with IGMP snooping and auto Voice VLAN for optimized communication. Dynamic VLAN assignment via RADIUS server with 802.1x client authentication is also supported.
Management & Monitoring
Accessible through HTTP/HTTPS, Telnet CLI, SNMP (v1/v2c), and RMON, with features such as port mirroring for traffic analysis, system logging, configuration backup, and firmware upgrades via TFTP or web interface.
Technical Specifications
- Ports: 18 GE total; 16 RJ45, 2 RJ45/SFP combo
- Memory: 128 MB
- Forwarding Rate: 26.79 Mpps
- Switching Capacity: 36 Gbps
- Jumbo Frame: 9K
- Dimensions: 440 x 200 x 44 mm
- Weight: 2.378 kg
- Operating Temp: 0–50°C, Storage Temp: -40–70°C
- Humidity: 10–90% RH
- Power Input: 100–240V, 0.7A max
- Spanning Tree: IEEE 802.1d/w/s
- QoS Scheduling: Priority queuing, Weighted Round Robin (WRR)
- Green Power Mode: EEE+, Short Reach + Energy Detect
- MAC Address Table: 8K
