The HPE ProLiant DL80 Gen9 Server delivers an ideal combination of performance, scalability, and manageability for service providers and SMBs in a 2U rack form factor. It supports up to two Intel® Xeon® E5-2600 v3/v4 processors and up to 256GB DDR4 SmartMemory, providing efficient, reliable computing for everyday IT workloads.
Storage and Expandability
Offers flexible storage with up to 12 LFF HPE SmartDrives supporting 10TB each, delivering a maximum capacity of 120TB SAS/SATA. Six PCIe 3.0 riser slots enable GPU or networking expansion, while embedded SATA and optional Smart Array controllers ensure high performance and reliable RAID or HBA configurations.
Networking and Management
Standard 2x1GbE with optional FlexibleLOM provides adaptable bandwidth. HPE OneView enables automated management, remote monitoring via iLO, and simplified firmware updates through Smart Update, reducing downtime and accelerating IT service delivery.
Efficiency and Reliability
Equipped with 80 PLUS Gold certified power supplies achieving up to 92% efficiency and ASHRAE A32 support for reduced cooling costs. Hot-plug redundant fans and drives enhance system availability.
Technical Highlights
- Processors: 1–2 Intel Xeon E5-2600 v3/v4, 4–14 cores, up to 3 GHz
- Memory: 8 DIMM slots, DDR4 SmartMemory, 256GB max
- Expansion: 6 PCIe 3.0 slots, 1 single-width GPU support
- Drives: 4/8/12 LFF SAS/SATA/SSD
- Management: iLO, Intelligent Provisioning, optional iLO Advanced
- Power: 2 entry-level PSUs, hot-plug fans
- Warranty: 1/1/1
