Key Features
Accelerates Applications Affordably
- One of the industry’s fastest entry-level arrays with 800 GB SSD capacity included.
- Built-in real-time tiering automatically moves hot data to flash and less-accessed data to cost-efficient media.
- Optimized SSD options for write-intensive or mixed-use workloads.
Simple and Efficient Management
- “Set it and forget it” operation with automated tiering.
- All-inclusive software suite and easy-to-use tools for IT generalists.
Disaster Recovery and Continuity
- 512 snapshots standard for rapid recovery.
- Remote replication included for affordable high availability.
Flexible Growth
- Data-in-place upgrades minimize migration and protect investments.
- Scales with a mix of SSD, SAS, and Midline SAS drives to meet evolving needs.
Technical Specifications
- Raw Capacity: Up to 96 TB
- Drive Options: (12) LFF SAS/MDL SAS supported
- Host Interfaces: 16 Gb/8 Gb Fibre Channel, 1 GbE, or 10 GbE iSCSI (4 ports per controller)
- Controllers: Dual MSA 2040 SAN controllers included
- Expansion: Supports MSA 2040 LFF or D2700 SFF enclosures
- Form Factor: 2U
- Dimensions (W x D x H): 44.7 Ă— 57.15 Ă— 8.9 cm
- Weight: 15 kg
Operating System Compatibility:
- Microsoft Windows Server 2008/2012, Hyper-V
- Red Hat Enterprise Linux, SUSE Linux
- HP-UX, OpenVMS
- VMware ESXi 5.x/6.x
- Oracle Solaris, Apple OS X
Additional Features:
- Clustering support for Windows, Linux, HP-UX, OpenVMS
- Built-in SAN backup and mirroring
- Systems Insight Manager support
- Includes two 400 GB mixed-use LFF SSDs (dual-controller system)
