Key Features
- Eliminate Buddy Punching
Traditional card systems can’t prevent “buddy punching,” where one employee clocks in for another. TA100C solves this issue with fingerprint verification, ensuring accurate identity-based attendance tracking. - Cloud-Ready Technology
Equipped with advanced PUSH technology, TA100C allows real-time data storage and seamless integration with TimeTec TA. This eliminates the hassle of manual data downloads and simplifies workforce management. - Simplified Data Management
With TCMS V3 software, businesses gain access to comprehensive features and reporting. Integration with third-party systems is supported via an SDK, making data handling more flexible. - Full-Color TFT Screen
The 3.0” color display provides a clear interface while allowing companies to showcase images, advertisements, and customized screen savers. - Workcodes for Efficiency
Employees can report work activities or whereabouts using the convenient workcodes feature, promoting independence and accountability. - Seamless Connectivity
TA100C supports TCP/IP for reliable communication. When unavailable, a USB flash drive can be used for easy transaction log transfers. Optional RS232, RS485, WiFi, and GPRS are also supported. - Custom Notifications
Short messages can be personalized and displayed on the terminal, keeping staff informed at every verification. - Cost-Effective Solution
Designed to be economical, TA100C delivers advanced biometric attendance tracking at an affordable cost.
Technical Specifications
- Model: TA100C
- Surface Finish: Acrylonitrile Butadiene Styrene (ABS)
- Processor: 800 MHz
- Memory: 256MB Flash, 128MB SDRAM
- Algorithm: BioBridge VX 9.0 / VX 10.0
- Dimensions: 190 Ă— 52 Ă— 140 mm
- Scanner Type: Non-coated optical scanner
- Fingerprint Templates: Up to 8,000
- Transactions: Up to 200,000
- Verification: Fingerprint (1:1, 1:N), Password
- Recommended Fingerprints/User: 2
- Verification Time: < 1 sec
- Accuracy: FAR < 0.0001%, FRR < 1%
- Connectivity: TCP/IP, USB Disk (Optional RS232, RS485, WiFi, GPRS)
- Baud Rates: 9600–115200
- Operating Environment: 0°C–45°C, 20–80% Humidity
- Power Input: DC 5V 2A
- Additional Features: Built-in/External Siren, Voice Guidance, Workcodes, Short Messaging
- Display: 3.0” 65K Color TFT Screen
