Features & Specifications
Key Features
- Advanced Surge Protection
Safeguards hardware with Over Current, Over Voltage, and Reversal Protection, ensuring longer product life. - Flexible Integration
Supports multiple Wiegand and card terminal formats, allowing easy adaptation to various security setups. - Real-Time Monitoring
Continuously tracks door status and events, enabling administrators to supervise openings and closings at all times. - Multi-Card Operation
Strengthens security in sensitive areas by requiring multiple cards for access. - Anti-Passback Security
Prevents untracked exits, ensuring complete traceability of all users. - Emergency Duress Mode
Provides secure alternatives for users during emergencies. - Unified Device Connectivity
Seamlessly integrates with CCTV, fire alarms, and building automation systems (BAS) for total security management. - Comprehensive I/O Ports
Equipped with ports for alarms, sensors, exit buttons, and other accessories for flexible deployment. - Reliable Data Communication
Ensures stable connections via TCP/IP or RS485 protocols. - Centralized Verification
Consolidates devices and verifications under one system for unmatched security efficiency. - Interlock Function
Supports interlocking logic where one door opens only after another closes, enhancing restricted-area security. - SDK Integration
Includes a free SDK for integrating with existing access control software or developing custom solutions.
Specifications
Models Available: Ingressus I, Ingressus II, Ingressus IV
- Dimensions (mm): I – 186×106×36 | II & IV – 226×106×36
- Power Input: 12V DC
- Operating Temperature: 0–55°C | Humidity: up to 80%
- CPU: 32-bit, 400MHz
- Memory: Flash 128MB, SDRAM 32MB | Polarity Protection: Yes
Storage Capacity:
- Fingerprints: 3,000
- Cards: 30,000
- Passwords: 30,000
- Transactions: 100,000
Communications:
- With Server: TCP/IP, RS485
- Terminals Supported: I – 2 | II – 4 | IV – 4 (max 2, 4, and 8 units respectively)
- Wiegand Inputs: 2–4 (26-bit), RS485 supported
Inputs:
- Push Release Button: 1–4
- Door Sensors: 1–4
- AUX: 1–4 (supports motion detectors, PIR, heat detectors, etc.)
Outputs:
- Door Locks: 1–4 (12VDC, 10A Form C relay)
- AUX Outputs: 1–4 (30VDC, 2A Form C relay, supports alarms, sirens, detectors)
Access Control Features:
- Door Opening Time (0–999s)
- Interlocking (Ingressus II & IV only)
- Anti-Passback (Local)
- Multi-Card Unlocking / First Card Unlocking
- 50 Time Zones + Holiday Scheduling
- Daylight Saving Support
- Continuous User Verification
Security Features:
- Door Force-Open Alarm
- Timeout Alarm
- Fire Linkage
- Duress Alarm
- 51 Event Types
Software:
- Bundled with Ingress management software
