Key Features
- Surge Protection
Protects security hardware with Over Current, Over Voltage, and Reversal Protection, extending product lifespan. - Flexible Integration
Supports multiple Wiegand and card terminal formats for versatile security system deployment. - Real-Time Monitoring
Tracks door status and access events continuously, ensuring full visibility and control. - Multi-Card Operation
Ideal for high-security zones, access is granted only when multiple cards are presented. - Anti-Passback Security
Prevents untraced exits to maintain strict access accountability. - Emergency Duress Mode
Provides alternate access options during emergency situations. - Unified Device Management
Connects CCTV, fire alarms, and building automation systems (BAS) under one platform for total security. - Comprehensive I/O Support
Includes ports for alarms, sensors, exit buttons, and other security accessories. - Reliable Communication
Enables data transfer via TCP/IP and RS485, ensuring stable connectivity. - Centralized Verification
Unifies devices and allows centralized verification for unmatched security performance. - Interlock Function
Ensures one door opens only after another is closed, offering enhanced control in restricted areas. - SDK for Integration
Free SDK provided for easy software integration or customization.
Specifications
- Models Available: Ingressus I, II, IV
- Dimensions (mm): I – 186×106×36 | II & IV – 226×106×36
- Power Input: 12V DC
- Operating Temp: 0–55°C | Humidity: up to 80%
- CPU: 32-bit, 400MHz | Memory: Flash 128MB, SDRAM 32MB
- Storage: 3,000 fingerprints | 30,000 cards | 30,000 passwords | 100,000 transactions
- Communications: TCP/IP, RS485
- Terminals Supported: I – 2 | II – 4 | IV – 4 (max: 2, 4, 8 units respectively)
- Inputs: Push button (1–4), Door sensors (1–4), AUX (1–4)
- Outputs: Door lock relays (1–4), AUX relays (1–4)
- Access Control Features: Door timing (0–999s), interlocking (II & IV), anti-passback, multi-card unlocking, time zones (50), holiday schedules, daylight saving, continuous verification
- Security Features: Door force alarms, timeout alarms, fire linkage, duress alarms, 51 event types
- Software: Ingress bundled
