SVS RS2 – 1U Form Factor. Compact 1U server solution for Video Surveillance. In the history of the surveillance industry, there has never been more focus on Quality, Reliability, and Cost Efficiency when it comes to selecting products for surveillance projects. Fibrenetix Storage Video Server (RS2 Value Point Series) has been designed to meet these ever-growing needs.
NVR, Playback Server, VMS Management Server Or Recording Server: The RS2 Value Point Series is a compact and versatile 1U, 4-bay server based on high-performance server technology, featuring Intel® Xeon® processor E-2100/E-2200 family, 8th/9th generation Intel® Core™ i3/Pentium®/Celeron® processors, and an award-winning RAID-5 engine. It delivers enterprise-level performance, ideal for VMS management and low-space recording with 16–64TB storage capacity.
Certified Performance: The RS2 Series is certified to run with major IP video management software, supporting up to 150+ cameras per server and providing longer retention capabilities than any other competitor in its class.
Tech Specs:
Series: RS2 SERIES – RS2-XXX-XX-AX SERIES
Product Code: RS2-123-XX-AX SERIES
Processor: Intel® Xeon® processor E-2100, E-2200 family, 8th/9th Gen Intel® Core™ i3/Pentium®/Celeron®
Number of CPUs: 1
Maximum Core per CPU: 6
Memory (Min|Max): 16GB UDIMM, up to 128GB UDIMM
OS Storage (M.2 Connectors): 2x M.2 240 GB SSD
Storage Bays: 4x Hot-swap 3.5” HDD Bays
Max. HDD Capacity Supported: 18TB
Maximum Raw Storage Capacity: 72TB
Max Capacity – Per IP SAN Controller: 9.2PB
Optional 10GBps Support: Yes
Network: 2 x Intel® I210AT + 1 Management LAN
Graphics (Standard): Aspeed AST2500 with 32MB VRAM
USB Ports: 2 x USB 3.1 Gen 2, 2 x USB 3.1 Gen 1
Video Ports: 1 x VGA port
Hot-swap Components: HDDs, PSUs
Power Supply: 1+1 Redundant 450W 80PLUS Gold
Voltage: 100-127/200-240Vac, 8A/4A, 47-63Hz, Class 1
Dimensions (D x W x H): 615 x 444 x 44 mm (1U)
Net Weight: 12.87 kg
Operating Temperature: 10℃ ~ 35℃
Warranty Period: 3 Years
BTU/hr: 1538.64
RS2 Benefits: Milestone Verified (System Builder Program), versatile storage capability, optimized thermal design with heat sink and heat pipe, best-in-class power efficiency and stability, high networking connection.
