Technical Specifications & Customization
Processor:
Supports 1x AMD SP3 processor, up to 32 cores, 180W TDP.
Bezel Options:
Optional LCD bezel or security bezel.
Dimensions & Weight:
- Depth: 60.65 cm (23.88 in.) for 8×2.5” drives, 65.72 cm (25.87 in.) for 4×3.5” or 10×2.5” drives
- Width: 43.4 cm (17.09 in.)
- Height: 4.28 cm (1.69 in.)
Drive Bays:
- Up to 10 x 2.5″ SAS/SATA/NVMe
- Up to 8 x 2.5″ SAS/SATA
- Up to 4 x 3.5″ SAS/SATA HDD
Embedded Management:
- iDRAC9 with Lifecycle Controller (no power capping)
- iDRAC Direct & REST API with Redfish
- Quick Sync 2 BLE/wireless module
Integrations & Connections:
- Microsoft System Center, VMware vCenter, BMC Software, Nagios Core/XI, HPE OMi
I/O & Ports:
- Network: Optional LOM 2×1GE, 2×10GE, or 2×10GE SFP+
- Front: Video, 1×USB 2.0, iDRAC Direct USB
- Rear: Video, Serial, 2×USB 3.0, dedicated iDRAC port
- Riser Options: Up to 2×Gen3 slots, 2×16 lanes
Memory:
16 DDR4 DIMM slots, supports RDIMM and LRDIMM
OpenManage Software:
OpenManage Enterprise, OpenManage Essentials, OpenManage Mobile
Power Supplies:
Platinum 550W, Bronze 450W
Support Options:
Dell ProSupport Plus or Dell ProSupport; consulting and deployment available
Supported Operating Systems:
Windows Server 2016/2012 R2, Red Hat Enterprise Linux 7.4, VMware vSphere 2016 U1 (ESXi 6.5 U1)
Storage Controllers:
- Internal: PERC H330, H730p, H740p, HBA330
- Boot Optimized: HW RAID 2×M.2 + USB + Dual SD Module
- External: PERC H840, 12Gbps SAS HBA, mini PERC x8
Security Features:
TPM 1.2/2.0 optional, cryptographically signed firmware, Silicon Root of Trust, Secure Boot, System Lockdown, Secure Erase
Performance & Scalability:
- Supports software-defined storage with Dell EMC ScaleIO Ready Node
- Up to 10 NVMe SSDs for high storage performance
- AMD EPYC processor with up to 128 PCIe lanes for high bandwidth and low latency access
