Specifications
General
- Product Series: SF110 | Product Line: Cisco Small Business
- Device Type: Unmanaged Switch (8 Ports)
- Enclosure Type: Desktop
- Port Type: 8 x 10/100 Fast Ethernet
- Power over Ethernet (PoE): Yes
Performance
- Switching Capacity: 1.6 Gbps
- Forwarding Rate: 1.2 Mpps (64-byte packets)
- MAC Address Table: 1000 entries
- Jumbo Frame Support: Yes
- Advanced Features: Flow control, Layer 2 switching, auto-negotiation, auto MDI/MDI-X, WRR queuing, QoS, cable diagnostics, loop detection, Energy Efficient Ethernet
- Compliant Standards: IEEE 802.3, 802.3u, 802.3z, 802.3ab, 802.3az, 802.1p, 802.3x, 802.3af
Indicators
- Power, Link/Activity, PoE, Cable Diagnostics, Loop Detection
Connectivity
- Interfaces: 8 x RJ-45 (10/100 PoE)
Power
- Power Device: External Power Adapter
- Voltage: DC 48 V
- Current: 1.25 A
Physical Specifications
- Dimensions (W x D x H): 5.1 x 5.1 x 1.2 in (130 x 130 x 30 mm)
- Weight: 1.2 lbs (545 g)
- Cooling: Fanless
Compliance
- Certifications: UL, CSA, FCC Part 15 (Class A), UL 60950, CSA C22.2
- Localization: North America
System Compatibility
- Supported OS: Linux, macOS, Microsoft Windows
Environmental
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Operating Humidity: 10–90% (non-condensing)
- Storage Temperature: -4°F to 158°F (-20°C to 70°C)
- Storage Humidity: 10–90% (non-condensing)
