Specifications
- Device Type: Unmanaged 5-port Fast Ethernet Switch
- Form Factor: Desktop, fanless design
- Ports: 5 x 10/100BASE-T RJ-45
- Switching Capacity: 1 Gbps
- Forwarding Rate: 0.74 Mpps
- MAC Address Table: 1000 entries
- Key Features: Auto MDI/MDI-X, QoS with WRR, loop detection, cable diagnostics, Layer 2 switching, flow control, auto-negotiation, Energy Efficient Ethernet
- Standards Compliance: IEEE 802.3, 802.3u, 802.3z, 802.3ab, 802.3az, 802.1p, 802.3x
- LED Indicators: Power, link/activity, cable diagnostics, loop detection
- Power Adapter: External, 12V DC, 500 mA
- Dimensions (W x D x H): 3.7 in x 3.6 in x 1.1 in
- Weight: 7.5 oz (approx. 213 g)
- Certifications: UL 60950, FCC CFR47 Part 15, CSA 22.2
- Operating Temp: 32°F to 104°F (0°C to 40°C), Humidity: 10–90% (non-condensing)
- Storage Temp: -4°F to 158°F (-20°C to 70°C), Humidity: 10–90%
- Languages Supported: Chinese (Simplified), German, French, Italian, Spanish, Japanese
- PoE: Not supported
- OS Requirement: None (Plug-and-play)
