Key Features and Specifications
Product Highlights:
- Dual-radio 2×2 MU-MIMO 802.11ac Wave 2
- Up to 1.3 Gbps* aggregate dual-band throughput
- Integrated enterprise security and guest access
- Built-in WIPS for threat detection and mitigation
- Application-aware Layer 7 traffic shaping
- Plug-and-play, self-configuring deployment
- Built-in location analytics and heat mapping
Radio Capabilities:
- 2.4 GHz 802.11b/g/n/ac & 5 GHz 802.11a/n/ac Wave 2 radios
- Supported frequency bands:
- 2.412–2.484 GHz
- 5.150–5.825 GHz (UNII-1/2/2e/3 depending on region)
- 2×2 MIMO with 2 spatial streams, MU-MIMO and SU-MIMO support
- 20/40 MHz (2.4 GHz), 20/40/80 MHz (5 GHz) channels
- Up to 256-QAM modulation
- Beamforming & Maximal Ratio Combining (MRC)
Antenna:
- Integrated omnidirectional antennas
- Gain: 4.5 dBi (2.4 GHz), 4.7 dBi (5 GHz)
Power & Consumption:
- PoE input: 37–57V (802.3af compliant)
- Max consumption: 11W
- Optional 12V DC input
- PoE injector sold separately
Interfaces & Mounting:
- 1x 10/100/1000BASE-T Ethernet (RJ45)
- Wall or vertical pole mounting (hardware included)
- Security screw included for physical protection
Environmental & Physical:
- Operating temp: -20°C to 55°C (-4°F to 131°F)
- Humidity: 5%–95% non-condensing
- Altitude: Up to 12,192 m (40,000 ft)
- IP67-rated enclosure
- Dimensions: 245 x 115 x 30 mm (9.65” x 4.53” x 1.18”)
- Weight: 0.45 kg (15.87 oz)
