SPECTRUM
- Channel Spacing: Configurable in 5 MHz increments
- Frequency Range: 5.150 – 5.970 MHz (subject to country regulations)
- Channel Width: 20 / 40 / 80 MHz
INTERFACE
- Physical Layer: Proprietary 2×2 MIMO/OFDM
- Ethernet: 10/100/1000 BaseT, compatible with Cambium PoE & standard PoE pinouts
- Supported Protocols: IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
PERFORMANCE
- Receive Sensitivity with FEC:
- @20 MHz: MCS0 = -87 dBm to MCS8 (256QAM-3/4) = -63 dBm (per chain)
- @40 MHz: MCS0 = -85 dBm to MCS9 (256QAM-5/6) = -59 dBm (per chain)
- @80 MHz: MCS0 = -82 dBm to MCS9 (256QAM-5/6) = -56 dBm (per chain)
PHYSICAL
- Environmental Rating: IP55
- Operating Temperature: -30°C to +60°C (-22°F to +140°F)
- Weight: 2.4 kg (5.3 lbs)
- Dimensions (Diameter x Depth): 47 cm x 31 cm (18.5 in x 12.2 in)
SECURITY
- Encryption: 128-bit AES (CCMP mode)
