Description
Physical Specifications
Dimensions: 5.8 x 2.7 x 7.4 in (148 x 68 x 189 mm) each
Weight: 1.06 lb (0.48 kg) each
The Orbi Pro WiFi 6 Mini Dual-band AX1800 Router does not support and will not pair with Orbi Home or Orbi Pro (WiFi 5) WiFi System Satellites.
Technical Specifications
Orbi Pro WiFi 6 Mini Dual-band AX1800 Router and Satellite offer speeds up to 1,800 Mbps† (1,200 + 600 Mbps).
Simultaneous Dual-band WiFi
• Radio 1: IEEE 802.11b/g/n/ax 2.4GHz – 256QAM support
• Radio 2: IEEE 802.11a/n/ac/ax 5GHz – 1024QAM support
High-Performance Antennas
Two (2) high-performance antennas with high-power amplifiers each
• Explicit Beamforming for 2.4GHz and 5GHz
• Integrated Gigabit Smart Ethernet Switch for business-grade security and applications
Networking Features
• 802.1Q VLAN
• Access Control
• MU-MIMO capable for simultaneous data streaming on multiple devices
Ethernet Ports – Orbi Pro WiFi 6 Mini Router
• One (1) Gigabit Ethernet WAN port
• Three (3) Gigabit Ethernet LAN ports
Ethernet Ports – Orbi Pro WiFi 6 Mini Satellite
• Four (4) Gigabit Ethernet LAN ports
Security
Four (4) SSID wireless networks:
• Administration devices
• Employee devices
• Guest devices with Captive Portal Challenge
• IoT devices
Guest WiFi Network is easy to set up for secure Internet access.
• Guest network devices are denied access to Administrative Network devices
• WPA/WPA2-PSK/WPA3-PSK support
• WPA-Enterprise
• Supports wireless and wired VLAN
