The Avaya 9504 Digital Deskphone is designed for everyday users—those who use the deskphone as one of several communication tools. Ideal for cubicle workers or retail sales staff, it provides reliable, high-quality voice communication with straightforward functionality.
Key Features:
Software & Call Control:
- Call control protocol: DCP
- Codec: G.711
- Secondary line alerting
- Native support on Avaya IP Office Release 7.0 and later
- Full access to IP Office call appearances and features
- Line/feature key buttons: 4 x 3 levels
- Contacts application: up to 100 entries
- Call log application (Missed/Answered/Outgoing calls): 30 entries
- User-selectable language options
Connectivity:
- Compatible with Avaya IP Office Release 7.0 or later
Hardware:
- Charcoal gray finish with handset and 9-ft cord
- Dual-position stand, wall-mountable option
- Message waiting indicator
- 4 contextual softkeys and 4 administrable buttons
- Permanently-labeled buttons: Speaker, Headset, Mute, Volume, Avaya Menu, Phone, History, Contacts, Voicemail
- Headset support and two-way speakerphone
- 2 wired line interfaces
Display:
- White backlit graphical LCD (181 x 56 dots; 4 rows x 32 characters)
- Permanently-labeled navigation cluster (Up/Down, Left/Right, OK)
Size & Weight:
- Weight including handset and stand: 2.0 lbs (926g)
- Depth (low position): 7 in (205mm)
- Width: 8.03 in (204mm)
- Height (low/high position): 6.34 in (161mm) / 7.91 in (201mm)
