The Aruba 2530 Switch Series offers a cost-effective, reliable solution for enterprise edge, branch offices, and SMBs seeking secure and managed Gigabit network access. This fully managed Layer 2 switch features 24 autosensing 10/100/1000 ports and 4 dedicated Gigabit SFP ports for uplink flexibility.
Performance & Connectivity
With a switching capacity of 56 Gbps and throughput up to 41.6 Mpps, the Aruba 2530 ensures high-performance data handling and smooth operation even in demanding environments. Its virtual stacking capability supports up to 16 switches, enabling simplified network expansion and scalability.
Features & Benefits
- Port Configuration: 24x RJ-45 autosensing 10/100/1000 ports and 4x Gigabit SFP ports.
- High Throughput: Supports up to 41.6 Mpps with low latency—< 2.3 µs for 1000 Mbps links.
- Power Efficient: Maximum power consumption of only 48 W, with heat dissipation at 164 BTU/hr.
- Robust Architecture: ARM9E @ 800 MHz processor, 128 MB flash, 256 MB DDR3 memory, and 1.5 MB dynamically allocated packet buffer.
- Flexible Management: Aruba Central, Aruba AirWave, CLI, web GUI, and out-of-band serial/USB access.
- Advanced Monitoring: Includes support for IEEE 802.3 MIBs, Ethernet Interface MIB, and Repeater MIB.
Power & Environment
The switch supports a wide input voltage range (100–127 / 200–240 VAC) and is ideal for standard office deployments with modest environmental demands.
Ideal Deployment
Designed for cost-conscious businesses needing secure and scalable Layer 2 Gigabit switching—ideal for office workgroups, SMBs, and branch networks.
