The 48-Port Managed Fast Ethernet Switch is designed for robust Layer 2 network operations. Supporting both desktop and rack-mountable installation, it delivers dependable performance for enterprise environments requiring VLAN segmentation, security, and enhanced traffic control.
Features & Benefits
Advanced Port Configuration
Equipped with 48 x 10/100 ports, 2 x 10/100/1000 uplink ports, and 2 x SFP slots, the switch supports seamless high-speed data transfers and flexible connectivity options.
Comprehensive Layer 2 Features
- Broadcast Storm Control
- IGMP Snooping
- VLAN and trunking support
- MAC address filtering
- Port mirroring for monitoring and diagnostics
- Auto-negotiation, auto-uplink (MDI/MDI-X), and flow control
Network Management
Remote configuration and monitoring via SNMP (v1, v2c), RMON (1,2,3,9), and HTTP interfaces. MD5 encryption and RADIUS authentication enhance access security.
Hardware & Build
- 1U desktop/rack-mountable metal chassis
- Internal power supply (AC 120/230V, 50/60Hz)
- Status LEDs for port activity and system diagnostics
Memory & Performance
- MAC Address Table: 8K entries
- RAM: 32 MB
- Flash Memory: 4 MB
Environmental & Compliance
- Operating temperature: 0°C to 40°C
- Humidity: 5% – 90% (non-condensing)
- Certifications: FCC Class A, TUV, C-Tick, EN 60950, UL 1950, VCCI Class A
Dimensions & Weight
- Width: 44 cm
- Depth: 32.2 cm
- Height: 4.4 cm
- Weight: 2.2 kg
